4" x 48" Pallet Rack Beam
4" x 48" Pallet Rack Beam
PH5/8-11X6SSHLTI KBTZ2 Hilti 5/8 X 6 KBTZ2 stainless steel ANCHORS HILTI 5/8 X 6

BEAM 4 H X 48L – 6IN CLIP

$0.00

  • Color: Orange
  • Beams lock into place with no hardware needed
  • Vertical adjustment on 2″ increments.
  • 2 beams are needed per level
  • All capacities are stated as uniform load
  • Step is 1-5/8″ tall to receive standard wire deck or 2×6 wood
  • 3 stud connector with automatic locking device

Stock Information

Scroll Location

Additional information

Weight 12.631 lbs
Dimensions 48.000 × 2.750 × 4.000 in
SKU

1000361436-178
Capacity

7628
Color

178-UNARCO ORANGE

Description

  • Beam length (actual storage space) 48″
  • Beam face height = 4″ tall with standard step height of 1 5/8″ tall
  • Beam Capacity 7,628 lbs. per pair, uniform load
  • Standard teardrop design that is compatible with most major manufacturer’s uprights
  • 3 heavy-duty studs and automatic locking device which locks into place when beam is properly seated
  • Check available crossbars or wire deck to support product loads
  • Please consult UNARCO Engineering for any shelf load over 10,000 lbs.
  • UNARCO rack designs conform to the latest Rack Manufactures institute (RMI) specifications and American Iron and Steel Institute (AISI) Cold formed Steel Design Manual
  • Add a J-Pin for additional beam uplift protection
